Products > CVD Diamond Tools > CVD Diamond Long Reach Drill Bit


CVD SEM closeup.png

SEM image of CVD diamond layer


Flank Wear Chart_CVD.png

CVD Diamond Coated tools show significantly
less wear than uncoated tools.



product overview

Through the process of Chemical Vapor Deposition, our CVD Diamond Coated Long Reach Drill Bit consists of a microcrystalline thin film of evenly distributed diamond particles of 3-6 μm on tungsten carbide substrate. The combination of CVD diamond, the hardest known material, and Tungsten Carbide, a very hard material, produces a tool that has exceptional service life. The diamond layer extends the life a carbide tool by 12 to 20 times longer, which decreases downtime due to fewer tool changes. As a physical barrier, the CVD diamond coating minimizes edge build-up and reduces wear of the tool. The diamond coating also has great thermal conductivity removing heat away from the cutting edge and increasing lubrication for better chip flow and evacuation.

Product Advantages

  • Exceptional service life

  • Less downtime

  • Increased efficiency and productivity

  • Less edge build-up

  • Faster heat dissipation

  • Excellent chip flow and evacuation

  • Improved surface finish

Materials Processed

  • Composites (PCB, GFRP, CFRP)

  • Engineered Plastics

  • Graphite

  • Ceramics

  • High Silicon Aluminum

Machine Compatibility

  • Milling Machines

  • CNC
